HPLC Syringe Filters
Material: Nylon; Hydrophilic PVDF; Hydrophilic PTFE; Hydrophobic PTFE; PES; MCE; Hydrophilic PP; Cellulose Acetate(CA)
Qty/Pack: 100pcs/pack
Application: Filter
Payment: T/T
MOQ: 1 pack
Details
1. Membrane: Nylon; Hydrophilic PVDF; Hydrophilic PTFE; Hydrophobic PTFE; PES; MCE; Hydrophilic PP; Cellulose Acetate(CA)
2. Pore Size: 0.22um and 0.45um Diameter: 13mm and 25mm
3. Usages: Whether your research requires pre-filtration
Description
|
Filter Membrane |
Nylon /PTFE /PES/MCE/ PVDF/ CA |
|
|
Pore Size, μm |
0.22μm, 0.45μm |
|
|
Diameter |
13mm |
25mm |
|
Housing |
PP |
PP |
|
Filtration Area |
1.0cm2 |
4.3cm2 |
|
Maximum Operating Pressure |
6.2bar |
6.2bar |
|
Process Volume |
10ml |
100ml |
|
Hold-up Volume |
< 25μl |
<100μl |
|
Inlet |
Female Luer Lock |
Female Luer Lock |
|
Outlet |
Male Luer Unlock |
Male Luer Unlock |
|
Flow Direction |
Flow should enter from the inlet |
|
|
Maximum Operating Temperature |
267.8F |
|
|
Sterilization |
Autoclave at 249.8F at 1 bar for 20 minutes/EO/Gamma |
|
Features
| Material | Characteristic |
|
PTFE |
PTFE membrane, hydrophobic, resistant to strong acid, strong alkali and high temperature, suitable for the filtration of strong corrosive solution, organic solution and gas. |
|
PVDF |
PVDF membrane, hydrophobic, low protein binding, suitable for general biological filtration, not suitable for filtration of highly corrosive liquids. |
|
Nylon |
Nylon membrane, hydrophilic, high protein binding, suitable for protein-free aqueous and organic solutions, resistant to alcohol and DMSO. |
|
PES |
Polyethersulfone resin membrane, hydrophilic, low protein binding, high flow rate, high porosity, not resistant to organic solvents and strong acid-base solutions, suitable for filtering cell culture media. |
|
CA |
Cellulose acetate membrane, hydrophilic, low protein binding, suitable for the filtration of proteins and aqueous solutions in biological samples, such as serum culture medium filtration. |
Technical Parameter
1. Aijiren New Syringe Filter
| 1.PVDF Syringe Filter |  |
 |
 |
 |
| Part No. | FF1322 | FF1345 | FF2522 | FF2545 |
| Description | Pore Size: 0.22um Diameter:13mm PVDF Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:13mm PVDF Syringe Filter Polypropylene Housing |
Pore Size: 0.22um Diameter:25mm PVDF Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:25mm PVDF Syringe Filter Polypropylene Housing |
| 2. PTFE Syringe Filter |  |
 |
 |
 |
| Part No. | FE1322 | FE1345 | FE2522 | FF2545 |
| Description | Pore Size: 0.22um Diameter:13mm PTFE Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:13mm PTFE Syringe Filter Polypropylene Housing |
Pore Size: 0.22um Diameter:25mm PTFE Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:25mm PTFE Syringe Filter Polypropylene Housing |
| 3.PES Syringe Filter |  |
 |
 |
 |
| Part No. | FS1322 | FS1345 |
FS2522 | FM2545 |
| Description | Pore Size: 0.22um Diameter:13mm PES Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:13mm PES Syringe Filter Polypropylene Housing |
Pore Size: 0.22um Diameter:25mm PES Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:25mm PES Syringe Filter Polypropylene Housing |
| 4.CA Syringe Filter |  |
 |
 |
 |
| Part No. | FC1322 | FC1345 | FC2522 | FC2545 |
| Description | Pore Size: 0.22um Diameter:13mm CA Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:13mm CA Syringe Filter Polypropylene Housing |
Pore Size: 0.22um Diameter:25mm CA Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:25mm CA Syringe Filter Polypropylene Housing |
| 5.Nylon Syringe Filter |  |
.jpg) |
 |
 |
| Part No. | FN1322 | FN1345 | FN2522 | FN2545 |
| Description | Pore Size: 0.22um Diameter:13mm Nylon Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:13mm Nylon Syringe Filter Polypropylene Housing |
Pore Size: 0.22um Diameter:25mm Nylon Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:25mm Nylon Syringe Filter Polypropylene Housing |
| 6.PP Syringe Filter |  |
 |
 |
 |
| Part No. | FP1322 | FP1345 | FP2522 | FP2545 |
| Description | Pore Size: 0.22um Diameter:13mm PP Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:13mm PP Syringe Filter Polypropylene Housing |
Pore Size: 0.22um Diameter:25mm PP Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:25mm PP Syringe Filter Polypropylene Housing |
| 7. MCE Syringe Filter |  |
 |
 |
 |
| Part No. | FM1322 | FM1345 | FM2522 | FM2545 |
| Description | Pore Size: 0.22um Diameter:13mm MCE Syringe Filter Polypropylene Housing |
Pore Size: 0.22um Diameter:13mm MCE Syringe Filter Polypropylene Housing |
Pore Size: 0.22um Diameter:25mm MCE Syringe Filter Polypropylene Housing |
Pore Size: 0.45um Diameter:25mm MCE Syringe Filter Polypropylene Housing |
